Precision Assembly
Ultra-accurate SMD and THT placement with zero margin for error.
Fast Turnaround
Rapid UK-based manufacturing cycles designed for critical engineering deadlines.
AOI Inspection
100% automated optical verification for total component and solder integrity.
Scalable Volume
Seamless transition from initial prototype builds to mid-batch production.
Direct Dialogue
Transparent, engineer-to-engineer communication throughout your project life-cycle.
The Manufacturing Story
A custom-engineered process where precision meets reliability. From first check to final delivery, every step is optimized for high-end PCB assembly.
01 Design Review & Board Check
Every project starts with a meticulous engineering board check. We verify Gerber files and BOM accuracy to detect errors before assembly begins.
02 Precision Paste Printing
Using advanced stencils and high-viscosity solder paste, we ensure perfect deposition on every pad, establishing the foundation for reliable conductivity.
03 Pick & Place Assembly
Advanced high-speed automated systems populate your boards with micron-level precision, handling everything from 01005 components to complex ICs.
04 Reflow Soldering
Multi-zone thermal profiling ensures controlled heating and cooling, creating robust metallurgical bonds without stressing sensitive electronics.
05 AOI Automated Inspection
Automated Optical Inspection scans every joint and component, identifying deviations instantly to maintain a 100% precision standard for every batch.
06 Final Build & Quality Certification
Detailed manual inspection and final cleanup. Your precision PCBAs are carefully packed and delivered ready for integration into your hardware ecosystems.
Manufacturing
Excellence
From rapid prototyping to medium-batch production, we provide precision-driven assembly solutions tailored for mission-critical electronics. Our UK-based workshop is engineered for the highest standards of SMD and THT assembly, ensuring your designs transition from Gerber to hardware without compromise.
SMD Assembly
Ultra-fine pitch precision using high-speed pick and place systems for complex, high-density multi-layer boards.
Prototypes
Rapid turnaround assembly cycles for engineering validation, allowing for fast iteration from design to hardware.
Production
Scalable UK manufacturing support for small to medium production runs with full process control and traceability.
THT Assembly
Specialist manual and wave soldering for through-hole components in power electronics and high-reliability modules.
AOI Inspection
Advanced Automated Optical Inspection verifying every solder joint and component orientation for zero-defect delivery.
Component Sourcing
Meticulous BOM management and component procurement through verified global supply chains to mitigate lead time risks.
Industries Served
OCD PCB delivers precision-engineered PCBA solutions for mission-critical operations where failure is not an option. Our assembly expertise supports the UK and Europe's most demanding sectors.
Aerospace & Defense
Uncompromising reliability for aviation and defense. We assemble boards designed to perform in the most extreme high-altitude and strategic environments.
Industrial Automation
Scalable hardware for resilient manufacturing. Our PCBAs power the sensors and control systems at the heart of modern industrial automation.
Medical Technology
Precision assembly for life-saving diagnostics and surgical devices. Our quality control ensures every PCB meets rigorous healthcare safety standards.
Telecommunications
Advanced signal integrity for high-data infrastructure. We manufacture boards optimized for 5G and high-bandwidth networking hardware.
Automotive & EV
Robust electronics for the next generation of mobility. We specialize in high-durability boards for power management and ADAS sensor arrays.
Renewable Energy
Specialized electronics for a sustainable future. We provide PCBA services for clean energy generation and advanced storage infrastructure.
Engineering Excellence
Reliability as a Standard, Not an Option.
At OCD PCB, we believe that high-end engineering demands uncompromising precision. Our UK-based workshop is built on a foundation of rigorous process control, utilizing advanced Automated Optical Inspection (AOI) and multi-stage manual reviews to ensure every solder joint and component placement is flawless. From single prototypes to complex production runs, we deliver the consistency and reliability that Europe's leading innovators depend on.
